Model | IPT35P |
Display | 3.5 inch Capacitive touch screen , resolution 4800(RGB)x 320 |
Network port | 10/100M auto adapt,RJ45 |
WIFI | Built in WIFI,speeds150M,display wireless camera image |
IP camera type | ONVIF,ACTi,Dahua IPC-HFW2100P,Hikvision,DS-2CD864-E13,Samsung SNZ-5200, Tiandy TD-NC9200S2,Kodak IPC120L,Honeywell HICC-2300T,Aipu-waton IP5000-BC-13MP/IRS06-13MP,fine-Tida IPC,FSJ BY-1080Q,WEISKY IPC camera etc. |
Video input/output | 1 channel BNC input & 1 channel BNC looped output, NTSC/PAL (Auto adapt) |
Video Level Test: | Video signals measured in IRE or mV |
Zoom Image | Support Analog camera and IP camera image zoom /move |
Snapshot, Video Record and Playback | Image Screen snapshot, record ,save ,view and record and play back |
12V/1Apower output | Output DC12V/1A power for camera |
Audio test | 1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphone |
PTZ control | Support RS232/RS485 control, Baud 600-115200bps, Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc |
Video Signal Generator | Output one channel PAL/NTSC color bar video signal for testing monitor or video cable.(red, green ,blue, white and black color ) |
color bar generator | Local side PC can login the tester, send the signal by network , test network connection communication whether normal |
UTP Cable tester | Test UTP cable connection status and display on the screen. Read the number on the screen |
Data monitor | Captures and analyzes the command data from controlling device, also can send hexadecimal |
Network test | IP address scan, link test, Ping test, Quickly search the connection IP camera and other device’s IP address |
PoE test | Measurement POE switch or PSE power supply voltage and cable connection status |
Power |
External power supply | DC 5V(1.5A ) |
Battery | Built-in 3.7V Lithium polymer battery ,.3500mAh |
Rechargeable | After charging3~4 hours, normal working time8hours |
Parameter |
Operation setting | Capacitive touch screen, OSD menu,Chinese/English |
Auto off | 1-30 (mins) |
General |
Working Temperature | -10 ° C - + 50 ° C |
Working Humidity | 30%-90% |
Dimension/Weight | 194mm x 112mm x 48mm / 540g |
