\\| \ System \ | \
\\| \ Main Processor \ | \\ Dual-core embedded processor \ | \
\\| \ Operating System \ | \\ Embedded LINUX \ | \
\\| \ Audio and Video \ | \
\\| \ IP Camera Input \ | \\ 4/8 Channel \ | \
\\| \ Two-way Talk \ | \\ 1 Channel Input, 1 Channel Output, RCA \ | \
\\| \ Display \ | \
\\| \ Interface \ | \\ 1 HDMI, 1 VGA \ | \
\\| \ Resolution \ | \\ HDMI:3840×2160, 1920×1080, 1280×1024, 1280×720 \ | \
\\| \ VGA: 1920×1080, 1280×1024, 1280×720 \ | \
\\| \ Decoding Capacity \ | \\ 1ch@8MP 30fps, 4ch@1080P 30fps \ | \
\\| \ Multi-screenDisplay \ | \\ 4CH: 1/4 \ | \
\\| \ 8CH: 1/4/8/9 \ | \
\\| \ OSD \ | \\ Camera title, Time, Camera lock, Motion detection, Recording \ | \
\\| \ Recording \ | \
\\| \ Compression \ | \\ H.265/H.264 \ | \
\\| \ Resolution \ | \\ 8MP/6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc. \ | \
\\| \ Record Rate \ | \\ 80Mbps \ | \
\\| \ Bit Rate \ | \\ 16Kbps ~ 20Mbps Per Channel \ | \
\\| \ Record Mode \ | \\ Manual, Schedule(Regular(Continuous), MD, Stop \ | \
\\| \ Record Interval \ | \\ 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec \ | \
\\| \ Video Detection and Alarm \ | \
\\| \ Trigger Events \ | \\ Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips \ | \
\\| \ Video Detection \ | \\ Motion Detection, MD Zones: 396 (22× 18), \
\and Tampering \ | \
\\| \ Alarm input \ | \\ N/A \ | \
\\| \ Relay Output \ | \\ N/A \ | \
\\| \ Playback and Backup \ | \
\\| \ Sync Playback \ | \\ 1/4 \ | \
\\| \ Search Mode \ | \\ Time /Date, MD and Exact Search \
\(accurate to second) \ | \
\\| \ Playback Function \ | \\ Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom \ | \
\\| \ Backup Mode \ | \\ USB Device/Network \ | \
\
\
