Item | Description |
Dimension | 108mm*108mm*16mm |
Weight | Only Device 0.19 kg |
With Accessories kg |
C кожзаменитель | S922X Quad-core ARM Cortex-A73 and dual-core ARM Cortex-A53processor |
Graphics | Hexa-core ARM G52 MP6 Graphics |
Amlogic Video Engine (AVE) with dedicated hardware decoders and encoders |
Support multi-video decoder up to 4Kx2K@60fps+1x1080P@60fps |
Supports multiple“secured”video decoding sessions and simultaneous decoding and encoding |
H.265/HEVC Main/Main10 profile @ level 5.1 High-tier; up to 4Kx2K @ 60fps |
VP9 Profile-2 up to 4Kx2K@60fps |
H.265 HEVC MP-10@L5.1 up to 4Kx2K@60f |
AVS2-P2 Profile up to 4Kx2K@60fps |
H.264 AVC HP@L5.1 up to 4Kx2K@30fps |
H.264 MVC up to 1080P@60fps |
MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496) |
WMV/VC-1 SP/MP/AP up to 1080P@60fps |
AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps |
MPEG-2 MP/HL up to 1080P@60fps (ISO-13818) |
MPEG-1 MP/HL up to 1080P@60fps (ISO-11172) |
RealVideo 8/9/10 up to 1080P@60fps |
Display | HDMI 2.1 output up to 4K@75Hz |
HDMI 3D video formats |
HDMI HDCP 2.2 |
AV(CVBS) 480i/576i |
Memory | 4г B (LPDDR4) |
Storage | 6 4г B(eMMC) |
Extended USB Mechanical Hard Disk 2.5/3.5inch 4TB Storage |
Extended Storage TF card |
Network | 2T2RWIFI IEEE 802.11 a/b/g/n/ac 2. 4г 5.8G |
LAN 1000M |
Bluetooth 4.1 |
Interface | USB3.0 | 2* USB Port |
USB2.0 | 1* USB Port |
HDMI | 1*HDMIA Type Port |
RJ45 | 1*RJ45 (1000Mbps) |
AV(CVBS) | 1*Headphone microphone jack |
TF Card | 1*MicroSD card Port |
DC-in | 1*DC in Port |
Remote control | Standard Infrared Remote(IR) |
Extended 2. 4г Remote |
|
LEDdisplay | GreenLED display |
Upgrade OS | 1* Upgrade button |
Software OS | Android 9.0 |
Adapter | 12V-1.5A 18W Certification Input: 100-240V~50/60Hz , Output:12V 1.5A |
Work Environment | -10°C--45°CС30%--90% Humidity |
Storage Environment | -20°C--60°CС10%--90% Humidity |
Accessories | 1*Adapter12V 1.5A |
1*HDMI Cable 80CM |
1*Manual |
|
